Electronic Wind Bell

• Porteur du projet : xiaohan guo user
• Fichiers utiles : mettre un lien vers un code ou un fichier

Create a enelctronic device with anenometer connected to arduino. Arduino drives several Mp3 readers.

Case :

• Nowind : no mp3 reading
• Little wind : few mp3 play - low audio volume
• Medium wind : more mp3 play - medium audio volume
• Little wind : allmp3 play - max audio volume

• Maya Dunietz, “Thicket” http://www.mayadunietz.com/new-gallery-12
• Erik Samakh
• Eol force , Impala Utopia https://jeromeabel.net/workshop/eol-force-5/

• Arduino
• wind sensor (anemometer)
• mp3 player (arduino) +sd https://github.com/salvadorrueda/SerialMP3Player
• amplifier
• Speakers
• Battery

• Anemometre branché sur A0 et GND.
• Lecteur mp3 - RX TX sur d11,d10 +5v et Gnd

#include "SerialMP3Player.h"
#define TX 11  // tx en fait
#define RX 10  // rx en fait
SerialMP3Player mp3(RX,TX);

// the setup routine runs once when you press reset:
void setup() {
  // initialize serial communication at 9600 bits per second:
  Serial.begin(9600);
  mp3.begin(9600);        // start mp3-communication
  delay(500);             // wait for init

  mp3.sendCommand(CMD_SEL_DEV, 0, 2);   //select sd-card
  delay(500);             // wait for init
}

// the loop routine runs over and over again forever:
void loop() {
  // read the input on analog pin 0:
  float sensorValue = analogRead(A0);
  // print out the value you read:

  Serial.println(sensorValue);
  delay(1);        // delay in between reads for stability

  if (sensorValue > 3) {
 mp3.play();     // Play "hello.mp3". You must hear "Hello World"
  mp3.setVol(sensorValue/5); // audio volume en fonction du vent...
  delay(10);
}
else {
 mp3.stop();     // Stop "hello.mp3". You must hear "Hello World"
 delay(10);
}
}
